Anti Intrusion using Active IR (Infrared beam)
Recently we did some security project
in Sentosa Cove and during our visit we are extremely impress with the
quality of the project be it condominium or even the bungalows and landed
properties there. The CCTV and security system in place was good and for
apartment the intercom, exclusive floors elevator control and card access
control system installed was in excellent condition. But we notice that
more can be done to further improve the security there as most of the
houses has no fencing and gate to keep intruders out, we feels that some
form of alert system can be install and yet do not affect the aesthetic of
the surrounding, thus we have brought in the Infrared Beam
system for the exclusive use in this kind of residential layout.
Basically we have classified
our Infrared beam system into the following category
Invisible Gate. Invisible
Perimeter intrusion Alert system. Invisible grill for Doors and Windows.
Internal Invisible Sectional intrusion alert system and even secured
wireless intrusion control and security management system. The
system uses the Infrared Beams to secured the premises, the wireless
system also prevent extensive reconstruction and modification to the
already renovated premises. The system can also be seamlessly integrated
to the existing home security system. The Infrared Beam install in these
premises keep intruder out by alerting the occupant in the premises and
yet do not modified the aesthetic nature of the premises. The movement
within the secured area is also not restricted. Most Motion detector in
premises will need to be bypass when the occupant is inside the premises
but for the Securitex Infrared Beam Technology System, the whole security
system
can still be armed even when occupant is in. Furthermore because this IR
beam are install very close to the doors, windows and glass panel thus
more movement area are allow within the open space premises. Below you
will find a detail write up on the Securitex Infrared Beam System. Feel
free to call us 67852171 or email
sales@securitex.com.sg if you
need presentation, we are most glad to work with you to improved your
security requirement.
Overview of the
Infrared Beam Security System
Ever dream of a grilled free windows and
door for clear view and yet have the benefit of safety and security. We at Securitex Electronic Systems Engineering after years of working on
infrared beam has now implemented the Patented FSLIM Pro which is an
infrared beam barrier that can be install on windows, doors and even
hallway to protect against illegal intrusion. The FSLIM transmit an
invisible IR beam across the opening of windows and door and when
this beam has been violated, the signal can be sent to a security
alarm panel to activate an alarm to warn the occupant of intrusion.
(Patented)
FSLIMPRO (2-4 beams)
To better understand how to use the
FSLIMPRO active infra-red barrier please
(Watch this Video)
The FSLIMPRO active infra-red
barrier has been designed and built to guarantee a
fast and easy installation. The electronics incorporated in
the profile with optic synchronism, reduce the amount of
connection cable laying to the minimum: power supply and
alarm contact.
They are available in profile from 0.5m to 3m. The
FSLIMPRO may be adapted to suit specific applications.
The type of the profile and the special shape of the caps
ensure a sealed fixing for external use. The beams can be
positioned at the desired height inside the FSLIMPRO
to personalized the protection level.
-
Range 12 m internal, 10 m on the
wall edge
-
Profile in anodized aluminium with
polycarbonate cover
-
Profile can easily be cut to adapt
to suit the height of the space
-
Integrated electronics ensure no
extra external enclosure needed
-
Multiplex and synchronized system
-
Expandable up to 8 pairs of
synchronized beams (with additional FSLIMPLUS
beams)
-
Anti-opening, tear-proof tampers
excludible with a jumper
-
Cable clamps, screws and O-Rings
supplied
-
1 output exchange relay N.O. /N.C.
-
Easy to install and align beams
thanks to four levels of power in the infrared
transmission
-
LED signals beam status (excludible
with jumper)
-
Operating mode selectable with
Dip-Switch.
|
|
|
Kit
barriers |
|
FSLIMRF05 |
Height 0,5
m - 2 beams |
|
FSLIMRF10 |
Height 1 m
- 4 beams |
|
FSLIMRF15 |
Height 1.5
m - 4 beams |
|
FSLIMRF20 |
Height 2 m
- 4 beams |
|
FSLIMRF25 |
Height 2.5
m - 4 beams |
| |
|
|
Height 3 m
version available on request |
|
Technical specifications
|
|
|
Power
supply |
12VDC |
|
Absorption |
Max
50mA with 8 beams |
|
Wavelength I.R. |
950nm |
|
Range |
12 m in
internal and 10m wall-flush |
|
Output contact |
1 N.O /
N. C |
|
Relay
Intervention time |
From
100ms to 1 s settable |
|
Restore
time |
0.5s |
|
Protection rating |
IP 55 |
|
Operating temperature |
from -20°
to +55° C |
|
Weight |
from 700 g
to 2500 g depending on the barrier |
|
FSLIMRF
(2-8 beams) (Patented)
FSLIMRF is a
battery powered active infra-red barrier for the
protection of balconies, doors, and windows which will
transmit alarm transmission via radio for a completely
wireless installation. The barrier is made up of two
aluminum the infra-red transmitter and receiver, within
the dark polycarbonate covers. The basic unit consists
of a master card to make up a two-beam barrier to which
may be expanded to include additional FSLIMPLUS
expansion beams can be added up to a maximum of 8.
The additional beams can be freely positioned inside the
profile, allowing the installer to adjust the beams to
suit any installation or application. Profile are
available in various sizes from 0.5m to 3m, to allow
adapted to suit specific needs. The type of the profile
and the special shape of the caps ensure a sealed fixing
and allow it to be mounted wall-flush externally
-
Range 7
m internal and 5 m wall flush
-
Battery
powered, 2 years battery life (10 radio transmissions
per day with 4 beams)
-
Optional additional battery kit
-
12VDC
linear power supply connection (if required)
-
Easily
to install (may be cut to fit various height
-
Expandable up to 8 pairs of synchronized beams
-
Flat
cable connections for ease of installation
-
Adjustment of reply time and intervention logic (via a
dip-switches)
-
Anodised aluminium profile and polycarbonate cover
-
Upper
and lower rubber caps with ventilating hole ABS
plastic to prevent condensation (misting) and the
intrusion of insects
-
Wall
fixing with screws and O Rings (supplied)
-
Anti-opening and anti-tear tamper (can be excluded
with a jumper)
-
Easy
installation and alignment of the barriers with a
buzzer.
-
With
FSLIMTX module: 433.920 MHz radio transmission
signaling: alarms, flat battery, tamper, supervision,
alarm end
-
With
FSLIMOUT module: 2 relay outputs for alarms
and flat battery signals for implementation on any
existing alarm via radio.
The
FSLIMRF05 infrared barrier is made up of a MASTER and a
SLAVE cards on one loop board. All the other barriers
FSLIMRF1015-20-25, consist of a MASTER card and SLAVE
card with 2 beams on board with two additional beams (n°
1 FSLIMPLUS) consisting of a pair of transmitter and
receiver probes. Each loop is made up of an infra-red
outward beam and a return beam; the MASTER transmits the
signal to the SLAVE that re-transmits it, amplified, to
the MASTER. The barrier can manage up to 8 beams (4
loops in total) and an expansion kit for two beams can
be purchased to expand it.
|
Kit
barriers |
|
FSLIMRF05 |
Height 0,5
m - 2 beams |
|
FSLIMRF10 |
Height 1 m
- 4 beams |
|
FSLIMRF15 |
Height 1.5
m - 4 beams |
|
FSLIMRF20 |
Height 2 m
- 4 beams |
|
FSLIMRF25 |
Height 2.5
m - 4 beams |
|
|
Height 3 m version available on request. |
|
Technical specifications
|
|
|
Power
supply |
3.6V
with 2 Lithium Thionyl Chloride batteries AA size 2.7Ah;
alternatively 12VDC power supply or additional 3.6V battery
to connect to the special connection. |
|
Absorption |
280
μA with 4 beams in standby; 550μA with 8 beams in standby; 10mA
during radio transmission with FSLIMTX module 20 mA during alarm
activation with FSLIMOUT module |
|
Battery
Life |
2
years, with 10 radio transmissions each day with 4 beams |
|
Intervention time |
300
ms or 900 ms, selectable with a dip-switch |
|
Alarm
frequency |
min.
10 s |
|
Wave length |
IR
950 nm |
|
Intervention logic |
interruption of 1 or 2 beams, selectable with a
dip switch |
|
Output |
with
FSLIMTX, radio transmission at 433 MHz. 5 channels with FSLIMOUT 2
relays (N.O. /N.C.) for alarms and fl at battery |
|
Alarm
types |
beam
interruption, beam restore, fl at battery, supervision (can be
excluded with jumper) tamper |
|
Supervision interval |
60
minutes |
|
Operating temperature |
-20°
to +55° C |
|
Radio
transmission range |
150m
in open environment, 50 m inside |
|
Settings |
selection of time and intervention logic, beam enabling |
|
Signals |
buzzer for aligning (active during aligning) Radio transmission LED
(excludible using jumper) |
|
Protection rating |
IP55 |
|
Weight |
from 700 g
to 2600 g depending on length of the barrier |
|
Active IR outdoor perimeter barriers
|
|
 INFRA
The INFRA column for infra-red perimeter barriers is
made up of INFRA profile in black Anodised aluminum with polycarbonate
cover and is available in lengths from 1m to 4m. With the appropriate
accessories it can be wall mounted, floor mounted or mounted on an
underground mounting base.
Inside the INFRA column the following can be fixed:
|
• beams
IOR5MS and
2PH60C beams with STIOR adaptor
• beams BIRAY200S beams with STBIRAY
adaptor
• beams
2PH150A and
4PH200A beams without adaptor
|
 |
|
More Active Infrared Beam protection system |
|
Suggested configuration for 1 column with wall
mounting:
|
Suggested configuration for 1 column with
direct floor mounting:
|
- INFRA column
- TAINFRA upper cap for column
- TINFRAB lower cap for column
- supports for wall mounting SUPINFRA: 2 pieces
every 2 m of column
- 1 power pack ALCO for column (Absorption max. 1 A)
- thermal unit TERMCOL2: 1 piece every 1.5 m of
column
|
- 1 INFRA column
- 1 TAINFRA upper cap for column
- 1 FLINFRA flange for column:
- FLINFRA45 for columns max height 2 m
- FLINFRA165 for columns over 2 m
- 1 power pack ALCO for column
- thermal unit TERMCOL2: 1 piece every 1.5 m of
column
|
|
FLINFRA165 for columns over 2 m:
|
- 1 INFRA column
- 1 TAINFRA upper cap for column
- 1 FLINFRA flange for column:
- FLINFRA45 for columns max height 2 m
- FLINFRA165 for columns over 2 m
- 1 BASEINFRA for column
- 1 power pack ALCO for column
- thermal unit TERMCOL2: 1 piece every 1.5 m of
column
|
|
Assembled measures
|
|
INFRA10 |
INFRA15 |
INFRA20 |
INFRA25 |
INFRA30 |
INFRA35 |
INFRA40 |
|
height 1 m |
height 1,5 m |
height 2 m |
height 2,5 m |
height 3 m |
height 3,5 m |
height 4 m |
|
|
Securitex Anti
Intrusion Division
